Solar Hybrid Inverter PCU UPS 12KVA Solar home backup device for blackout and solar feed in 12kW

FOB Reference Price:Get Latest Price
$1,350.00 - $1,450.00 / Pieces | 8 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Turkey
Brand Name:
Depar
Model Number:
DH12000
Output Power:
12kVA
Output Type:
Single
Size:
395*555*605
Weight:
85kg
Input Voltage:
192V
Output Voltage:
AC220V
Type:
DC/AC Inverters
Output Frequency:
50Hz
Output Current:
AC 55A
PV Input Voltage:
192V
PV Input Current:
25A
PV Power Control:
PWM
Output Phase:
1 Phase
DC Isolation:
Inbuilt Transformer
Max Input Voltage:
350V
AC Grid Voltage Input:
100-280V
Wave Type:
Pure sinusodial
THD:
< 3%
Charging Method:
AC or Solar, setup function
Supply Ability
Supply Ability:
500 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Export Euro Pallet, 8 pcs per pallet.
Port
Istanbul
Lead Time :
10 days



Depar Solar Hybrid PCU 12kVA with Inverter, UPS and Solar home backup device for blackout and solar feed in 12kVA

Smart Solar Selection based on built-in Real Time Clock

-        For maximum utilization of Solar Power

-        To get the optimum performance of the PCU for Max. Power Saving.

-        To monitor abrupt weather conditions

Real Time Clock divides the dayin 4 Time slots:

-       When Sun Rises (Increasing Intensity)

-        During Afternoon (Stable Intensity)

-        When Sun Sets (Decreasing Intensity)

-        Night Time (No Sun)



It's Intelligent Hardware & Smart Solar Selection Algorithm tracks the sun position for MaximumUtilization of Solar Power for Maximum Power Saving based on Time Zone and following Inverter/Solar Parameters like:

-   Battery Voltage

-   Discharging AH

-  Solar CurrentCapacity        -  TotalSolar Current

-   Solar Coefficient (derived by previous day Solar Capability)



50/70 Amp. PWM / MPPT built-in Solar Charge Controller

-   Inbuilt fully regulatedPWM / MPPT(optional) 50 Amp. / 70 Amp. Solar Charge Controller to get optimum utilization of Solar Power.

- Provision for Charging by Solar Power Only

- Maximum Grid Power Saving can be achieved by “Charging by Solar Power Only” Button

-  Provision to maintain Battery Gravity

-  For better battery performances they are charged at full 15V (adjustable) level once in a month to maintain the gravityand prevention from deep discharge conditions.



Provision for setting of Critical Parameters as per user requirement

-   Time (in a separate menu)                 - Boost Battery Voltage

-   Battery Low Cut Voltage                    - Solar Low Batt. Low Cut Voltage

-    Solar Max Charging Current              - Mains High Charging Current

*Solar KWH on digital display

Priority to Solar Power

* Remote Monitoring & Controlling of the UPSSystem through Wi-Fi / LAN / GPRS / Android App.(Optional)





Description

Specification

About Technology

Type of Inverter

TRUE HYBRID (Dual Input Source DC Type)

Nominal Rating

As Per Annexure

Max PV input Power

[50.0 Amp x (Specified Vdc x 1.5)] Wp

Control type

MOSFET

Power Control

PWM

Output Phase

1 Phase

DC current isolation

By Inbuilt Transformer

Grid Terminal

Appropriate rating terminal out for plug-IN

Solar Terminal

Power Terminals 80 Amp.

Operating Parameters

Solar Input Voltage range

[1.083 x Specified Vdc] to [1.666 x Specified Vdc] V

Max Solar DC Input Voltage

[1.83 x Specified Vdc] V

Max Dc Solar current

50 A

Input Grid AC voltage Range

UPS:-180 - 260 V, INV:- 100 - 280 V

Input Grid AC frequency Range

50 Hz ± 1.0 Hz

Output Voltage @ Batt. Full Charge

200 - 220 VAC

Wave Out type

pure sinusoidal

Total harmonic distortion (THD)

< 3 % for Resistive Load

Output frequency

50 Hz (±1.0 Hz)

Charging Method

Active Advance Battery Voltage dependent with multi controls for ripple free Charging

No-Load Loss

As Per Annexure

Overload Capacity at <= 120 %

5 sec

Overload Capacity at > 200 %

Immediate trip

Peak efficiency

≥ 85 %

Working Conditions

Temperature : 0 deg C to + 45 deg C, Humidity≥: 95 %

Noise emissions (dBA)

< 50 dB at 1mtr

Maximum operating altitude

1000 mtr

Protections

Surge Protection

Available

Reverse polarity protection for Battery

Available

Reverse polarity protection Solar

MOSFET based

Battery Protection

Automotive Fuse/ MCB (Type C curve)



Grid Protection

MCB (Type C curve)

Load Protection

Automotive Fuse/ MCB (Type C curve)

Internal fault protections:-

1.          Over temperature protection

Available

2.          Over load protection.

Available

3.          Short circuit protection.

Available

DC Under voltage protection Per Batt.

10.4 V +/- 0.3V

AC Under / Over voltage protection

UPS:-180 - 260 V, INV:- 100 - 280 V (With 10 V Hys.)

Audio warning/alarms

BUZZER with Back Light Color Change feature

Emergency off button

Push to OFF

Display on front panel

Customized LCD Display.







SYSTEMRATING





SPECIFIED

Battery Volt





Max. No Load Loss





(NC) Charging A (Mains, Solar)



(HC)

Charging A (Mains, Solar)







Net Size







Gross Size





Net Weight





Gross Weight

12.0 KVA

192 V dc

<= 180 W

12.0 A, 25.0 A

15.0 A, 32.0 A

275 x 475x 560

395 x 555 x 605

71.15

81.00

20.0 KVA

360 V dc

<= 288 W

12.0 A, 25.0 A

15.0 A, 32.0 A

275 x 475x 560

395 x 555 x 605

100.00

110.00

Accessible Parameters Via Operating Display

1. AC mains voltage

7. Faults Status

2. O/P Load in %

i) Overload

3. Battery input voltage

ii) Short Circuit

4. Battery Charging/ Discharging current (Bar Graph)

iii) Fuse Trip

5. Solar KWH used

iv) Over Temp.

6. Solar Status

v) Empty ‘Battery’ Blinking

 Smart Solar Selection Logic based on built in Real Time Clock.

Provision for Charging by Solar Power Only. Provisionfor setting CriticalParameters of Solar. Provision for setting backuptime.

Provision for maintaining the battery gravityonce in month.

Ability to provide rated output power directly from solar panels (if solar is available) in addition charges the battery simultaneously.

Intelligently give the priority to solar power and take the balance from Mains.
